DAR 3000 Drop-down frame
Drop-down frame for full integration of DA 336x/brDA 34xx.
- Option to fully integrate DA 336x / DA 34xx
- The rangehood is not visible in the wall cabinet
- Installing DA 3496 in cabinet (W: 60 cm) not possible w. DAR 3000
$ 344.00
Low in stock. Click ADD TO CART
to check stock availability
to check stock availability
Description
09188880
- Option to fully integrate DA 336x / DA 34xx
- The rangehood is not visible in the wall cabinet
- Installing DA 3496 in cabinet (W: 60 cm) not possible w. DAR 3000
Installation Drawings
Find all installation drawings below
DAR 3000 (Installation drawing)
1. Vented, 2. Recirculation with conversion kit DUU 151, 3. Cabinet korpus has to be shorten 50 mm compared to the cabinet door., For all other cabinets, details in DA 3360, 3460, 2380 and 3490 dimensioned drawings apply. , A housing unit base is not required., Installing a DA 3490 in a 60 cm wide housing unit is not possible with the drop-down frame., Safe distance to cook top has to be kept by deepen cooker hoods
